English
English
Giant Brain
2.5 times full-size, 14-part
Assembly instructions
Position the base so that the 3B logo shows to the front left.
Assembly of the right brain half, fig. A (horizontal sections)
• Place part 1 into the base, ensuring an exact fit.
• Insert the metal connecting pin into part 2, so that it protrudes in equal length at the top and bottom.
Now connect part 2 with part 1.
• Insert part 3a into part 3 and connect both with part 2.
Assembly of left brain half, fig. B (vertical sections)
• Insert the metal connecting pin into part 5, so that it protrudes in equal length at the top and bottom
• Connect parts 4 and 6 with part 5 and insert all into the base.
Assembly of brain stem, cerebellum and pituitary gland
• Place part 8 onto part 7 and insert both into part 4.
• Place part 10 onto part 11.
• Connect parts 10/11 with part 9 and insert all behind the encephalic trunk.
• Place part 12 onto parts 3a and 5.
Overview of line drawings
Fig. 1
Surface of brain, cranial view (right half numbered)
Fig. 2
Surface of brain, lateral view of grooves (left half)
Fig. 3
Surface of brain, caudal view
Fig. 4
Surface of brain, caudal view
Fig. 5
Right half of the brain, medial view
Fig. 6
Model part 6: frontal section, dorsal view
Fig. 7
Model part 5: frontal section, ventral view
Fig. 8
Model part 5: frontal section, dorsal view
Fig. 9
Model part 1: horizontal section, caudal view
Fig. 10
Model part 2: horizontal section, cranial view
Fig. 11
Model part 2: horizontal section, caudal view
Fig. 12
Model part 3: horizontal section, cranial view (without part 3a)
Fig. 13
Model part 3a: frontal section, dorsal view
Fig. 14
Model parts 9, 10, 11 (= cerebellum): dorsal view
Fig. 15
Model parts 9, 10, 11 (= cerebellum): ventral view
Fig. 16
Model part 10: horizontal section, caudal view
Fig. 17
Model part 4: frontal and diagonal section, medio-caudal view
Fig. 18
Model part 3a: horizontal section, caudal view
Fig. 19
Model parts 7, 8: ventral view
Fig. 20
Model parts 7, 8: dorsal view
