7. Assemble the accessories on the body
case.
5. Assemble the stick into the body case.
Press the button on the stick, We can pull
out the stick from the body case.
6. Assemble the turbo brush
Press the button at the bottom of the body
case , We pull out the brush from the body
case.
www.vitesse.ru
P/3 P/4
ASSEMBLY
Warning: Always unplug from electrical outlet
before opening the dust cup (container) (5).
Note: Dust cup filter (6) must be used when
operating the hand vacuum.
1. To open the dust cup (container) (5), push
button (2)and pull out the dust cup (5).
Verify that the dust cup filter (6) is inside,
then attach the dust cup (container) (5) to
the hand vacuum.
2. To attach the Upholstery Nozzle (7), or
crevice brush (8) to the vacuum cleaner,
push brush into the suction hole (1), as
shown below.
3. Put the appliance into the body case
4. Also we can put the appliance out of the
case
a. Pull the button on the body case to the back
position
b. Put the vacuum cleaner out of the body
case.
HOW TO OPERATE YOUR HANDY VACUUM
• Hold the hand vacuum firmly with your hand on the Handle (4).
• Push the
I/ O Power Switch (3) to “ ” position.
• Start vacuuming.
I
CAUTION:
The Hand Vacuum is a very powerful unit. Make sure that you hold
it firmly, otherwise it can slip out of your hand and cause injury.
CHANGING & CLEANING THE DUST CUP FILTER
Warning: Always unplug from electrical outlet before opening the Dust Cup
(container) (5).
• To open the Dust Cup (container) (5), push button (2) and pull out the Dust Cup
(container) (5), (fig.1).
• Pull out the Dust Cup Filter (6), (fig.2).
• Empty the dust from the Dust Cup Filter (6).
• Rinse the Dust Cup Filter (6) in cold water, and then wait until it dries up before
replacing it into the Dust Cup (container) (5).
• Place the Dust Cup Filter (6) carefully into the Dust Cup (container) (5).
• Attach the Dust Cup (container) (5) to the Hand Vacuum.
fig.2
CAUTION:
The suction hole (1) must be open, free of any obstructions at all time.
Otherwise, the motor will overheat and could get damaged.
fig.1
