P/3 P/4
Operation and function
1. Starting
2. Fitting / removing the flexible hose
3. Fitting/ Removal of the suction
tubes/floor nozzle
4. Pulling out/ rewinding the cable
Before starting your vacuum cleaner
for the first time, check that all filters
are inserted correctly. Important: the
cleaner cover will only close if the dust
filter is inserted.
Fit the flexible hose to the suction
opening on the upper side of the
housing. Press the hose connection
into the air inlet until you feel it click into
place. Press the button on the hose
connection, and pull the hose out
again.
The metal tubes consist of 2 pieces.
The two tubes and the adjustable floor
nozzle are connected by pushing
t o g e t h e r a n d t u r n i n g , a n d
disconnected by pulling and turning.
Pull the cable out far enough to be able
to work comfortably. Then insert the
plug into the power socket. The mark
indicates the ideal working length. Do
not pull the cable out any further than
the red mark. To rewind the cable,
press the rewind button while feeding
the cable back in with the other hand to
prevent damage to the housing by the
cable.
5. Use of the adjustable floor nozzle
Note:
6. Changing the motor filter
7. Replacing the exhaust air filter
8. Power Control
9. Auxiliary air regulator
10. Switching On and Off
The floor nozzle can be adjustable manually, and is
suitable for bother carpets and for hard floor
coverings (the brushes should project for hard floor
coverings)
Please also observe the cleaning and care
instructions of your floor covering suppliers.
The motor filter protects the motor against dust
residue. The motor filter is located between the dust
container and the motor, and is removed after first
opening the vacuum cleaner. The filter must be
replaced if it is obviously damaged. Otherwise
simply shake or blow the dust out. Replace the filter
in its housing. Ensure that the filter is sitting straight
in its housing and closed evenly.
The exhaust air filter ensures clean air during the
vacuuming process. The filter should be replaced
regularly whenever it becomes dirty. To remove the
exhaust air filter, open the vacuum cleaner and
remove the filter grill. Now remove the filter from the
grill. Insert the new filter into the grill and refit it to
the rear side of the unit. Ensure that the filter is
sitting straight in its housing and closes flush.
The Electronic power control is used to adjust the
vacuum performance to the cleaning situation in
question by means of the rotary power switch.
The auxiliary air regulator is used for the easy,
temporary reduction of the vacuum performance.
Open the auxiliary air regulator only as far as
required until the vacuum nozzle can be moved
easily.
The vacuum cleaner is switch on/off by pressing the
on/off switch.
Note: If the vacuum cleaner is to be used for longer than 30minutes, the
power supply cable should be pulled out at 2 / 3 of its total length, to prevent
danger of over heating and damage.
