ViTESSE VS-280 - Инструкция (Страница 3)

www.vitesse.ru
P/3 P/4
FEATURES:
Air Purifier is specially designed compact unit with the power of an ionizer more
than twice its size. If operates using negative ions that pull in polluted air, trap
contaminants, and release clean, healthy air. This Air purifier is energy efficient, it
only consumes up to 12Watts of power and effectively covers up to 20 centiare.
There are no expensive filters to replace, the collection grid filters the air by
trapping airborne particles, pollutants and allergens that are in the air. Compact
design is perfect for desk or shelf.
Operating Your Air Purifier
1. For best air circulation, make sure that the Air Purifier is at least 6inch. away
from wall or any large objects. Place the unit on a desk, table or shelf.
2. Before connecting the unit, make sure that the Collection Grid is inserted
properly. Just pull out the Grid and reinsert it .The Collection Grid can be
inserted one way only. Follow the grooves on the top of the unit. Slide the
Collection Grid in until you hear a click.
3. Plug in the unit.
4 Press down the button and the unit will create negative ions that pull in polluted
air, trap contaminants, and release clean, healthy air. The additional Fan
increases air circulation, therefore making the Purifier more effective.
Button
Coleotion glid
ION
FAN
UV
CLEANING
Cleaning the Collection Grid
Clean the grid every one or two weeks.
1. Before cleaning,unplug the unit.
2. To remove the collection grid,pull it from the right
side of the unit.
3. To quickly wipe the dust from each of the three
collection bars,use a dry or slightly damp towel
or sponge.
Germicidal Lamp Replacement
Lamps are effective for 6000 hours,or about 8 months of continuous use.Replace
earlier if there is no “blue glow”inside the housing,when the unit is running in UV
mode.
Oil from fingers will reduce the germicidal performance of the UV lamp.DO NOT
allow fingers to come in contact with the glass.Use gloves or handle only by the
metal area of the lamp.If you touch the lamp or need to clean it for any
reason,wipe with a paper towel dampened with alcohol or any ammonia-based
cleaner
1. To unlock the back cover, slide the LOCKING TAB open.Remove the back
cover by lifting it up and sliding it up and out.
2. Turn the lamp 1/4 turn and slide it from its fixture.Replace with a new lamp of
the same type.
Replacement lamps are available directly from The Sharper Image.Consult
your local regulations for the proper disposal method of used fluorescent
lamps.
The unit will not function while the collection grid is removed and/or the
germicidal lamp cover is removed.
