Attention:
Before attaching or detaching any accessories always ensure that you
unplug the power supply from the wall socket!
1. Attaching or detaching the hose:
To attach: Push the vacuum hose into the air intake opening until it
snaps into place.
To detach: Push the button on the vacuum hose to release the hose.
2. Attaching the tube and its accessories:
• Mount the tube onto the handle
• Now attach the floor brush to the tube as shown in the diagram.
Operations:
Before use ensure that you have released a sufficient length of cable,
and then plug the device into the wall socket. The ideal cable length is
identified on the cable by a yellow marking. When unrolled, the cable
should not exceed the maximum length. This is identified by the red
The HEPA filter
Emptying the dust receiver tank:
Always unplug the appliance before emptying the dust receiver tank!
Press the switch and pull the dust tank upright, show as the picture.
Hold the dust receiver tank over your dustbin and pull the interlock device
back, show as the picture.
Once the tank is empty it is recommended that the HEPA filter be cleaned if
necessary.
• Carefully turn the HEPA filter in “loose” clockwise direction, until it
disengages. Now remove the HEPA filter.
• Clean the HEPA filter thoroughly. Never clean the HEPA filter using soap
or any other cleaning fluid. This would destroy the filter!
• If the HEPA filter is heavily soiled, and this is leading to a reduction in
suction power, it is recommended that the filter be replaced with a new
one.
