DEAR CUSTOMER!
You have made an excellent decision. Vitesse® “Nouveau” home range offers
you an exclusive, high quality range of appliances for your ultimate home
luxury and healthy living.
IMPORTANT SAFEGUARDS
When using an electrical appliance, basic safety precautions should always
be observed, including the following.
READ ALL INSTRUCTIONS BEFORE USING
VACUUM CLEANER
1) COMPONENTS LIST
2) OPERATING MODE:
1. Connect the hose accessories:
Press the adaptors at both side of the hose end, then insert the hose into
the hose socket.
2. Connect the metal tube to the curved end of hose.
3. Connect the different nozzle tools/floor brush/ turbo brush to the tube for
different cleaning purposes. The floor brush has two positions, soft/textile
surfaces. The combi nozzle is for narrow surfaces.
4. Turn on the appliance:
Hold the plug and pull out the cord, then insert the plug into the power
socket. Make sure that the power supply corresponds to the required
power mentioned on the rating label. Press the on/off switch pedal to turn
on the power. Adjust power to the required level.
5. Turn off the appliance:
After using, press the on/off switch pedal, the appliance is turned off. Pull
the plug out of the power socket, press the cord rewinding pedal, the power
cord will be drawn in.
6. To move the appliance from room to room, unplug and carry it by using the
handle. Never pull the appliance by its cord when moving.
3) MAINTENANCE:
* Paper or Cloth dust bag
1. When the dust tank is full, it is time to clean the dust. To do that, please
follow the instructions:
(a) Open the front cover by pressing the lock clip
(b) Lift off the Paper bag from dust bag hold. Please always keep the dust
inlet hole upper in order to void dust leakage.
(c) Empty the dust bag and install the dust bag to the holder. Make sure the
card of dust bag reach to the bottom of dust holder.
(d) Close the front cover.
P/1 P/2
Read the instruction manual carefully
before using this vacuum cleaner!
If the supply cord is damaged, if must be replaced by the manufacturer or
its service agent or a similarly qualified person in order to avoid a hazard.
1. ON/OFF SWITCH PEDAL
2. HANDLE
3. CORD REWINDING PEDAL
4. POWER REGULATING
SWITCH
5. FRONT COVER
6. HOSE SOCKET
7. AIRFLOW INDICATOR
8. BOTTOM BRACKET
9. OUTLET BOARD
10. PARKING HOOK
11. WHEEL
12. POWER CORD
13. COMBI NOZZLE
14. TUBES
15. HOSE
16. FLOOR BRUSH
17. TURBO BRUSH
