P/3 P/4
• Support or press the centre of the cutting plate with one finger then screw the
fixing ring until tight with another hand (fig.4). Do not over tighten.
• Holding the head and insert it in the inlet with one hand, tighten it clockwise to
secure the head .(fig.5,6)
• Place the hopper plate on the head and fix into position.
• Locate the unit on a firm place.
• The air passage at the bottom and the side of the motor housing should be
kept free and not blocked.
MINCING MEAT
•
Cut all foods into pieces (boneless and fatless meat is recommended,
approximate size :20 mm x 20 mm x 60 mm) so that they fit easily into the
hopper opening.
• Plug in and turn the “R / ON” switch to "ON" position, then turn the “ON/OFF/
Reverse” switch to "ON" position.
• Feed foods into the hopper plate. Use only the food pusher (fig.8).
• After use switch the unit off and unplug it from the power supply.
REVERSE FUNCTION
•
In case of jamming switch the appliance off by turning the “R / ON” switch to
"R" position and “ON/OFF/ Reverse” switch to "R" position.
Feed screw will be rotating in the opposite direction, and the head will get
empty.
• If it doesn't work, switch the unit off, plug out and clean it.
MAKING KIBBE
RECIPE
STUFFING
Mutton 100g
Olive oil 1 tablespoons
Onion (cut finely) 1 tablespoons
Spices to your taste
Salt to your taste
Flour 1 tablespoons
•
Mince mutton once or twice.
• Fry onion until brown and add minced mutton, all spice, salt and flour.
OUTLET COVER
Lean meat 450g
Flour 150-200g
Spices to your taste
Nutmeg (cut finely) 1
Powdered red pepper to your taste
Pepper to your taste
•
Mince meat three times and mix all ingredients together in a bowl. More meat
and less flour for outlet cover creates better consistency and taste.
• Grind the mixture three times.
• Disassemble by reversing the steps from 5-3 to remove the cutting plate and
cutting blade.
Place kibbe attachments A and B onto the feed screw shaft together, fitting
protrusions in the slots (fig.9).
•
Screw fixing ring into place until tight. Do not over tighten (fig.10).
• Make the cylindrical outlet cover (fig.11).
MAKING SAUSAGE
•
Before starting please assemble sausage attachment as per following (fig.12)
CLEANING AND MAINTENANCE
DISASSEMBLING
•
Make sure that the motor has stopped completely.
• Disconnect the plug from the power outlet.
• Disassemble by reversing the steps from (fig.6) pictures.
