ENGLISH
Disassembly
1. Make sure that the appliance is switched off and unplugged
from electrical outlet.
2. Take the pusher (1) (1) (1) (1) (1) out of the feeder tube (2) (2) (2) (2) (2). Lift the safety
clamps (7) (7) (7) (7) (7) and move aside and down.
3. Remove the lid (2) (2) (2) (2) (2). Then remove the grater/filter (3) (3) (3) (3) (3).
4. Unfasten the pulp container (4) (4) (4) (4) (4). Then the holder (6). (6). (6). (6). (6).
Operation
1. Assembly the appliance (See «Assembly») and plug it in. Before
plugging in make sure that the switch (10) (10) (10) (10) (10) is in «0» «0» «0» «0» «0» position
and that the safety lock (7) (7) (7) (7) (7) is properly locked.
2. Wash the food before processing. You may process the whole
small-size fruits and vegetables (carrots, small apples, toma-
toes). It is necessary to cut large-size fruits and vegetables into
pieces of such a size that they freely pass into the feeder tube (2) (2) (2) (2) (2).
3. Switch on the juice extractor by selecting the required speed
«1» «1» «1» «1» «1» or «2» «2» «2» «2» «2» with the help of the switch (10) (10) (10) (10) (10). In order to
operate the juice extractor efficiently, use the first speed when
extracting juice from soft food (for example, tomatoes); and the
second speed is recommended when processing hard food (such
as carrots).
Note: run the juicer for 1 minute at a time only, then
switch it off for a while to get cooled.
4. Lower the fruits or vegetables into the feeder tube (2) (2) (2) (2) (2), carefully
pushing them with the pusher; in so doing the motor should
run. Do not push the food into the juice extractor using excessive
force. This will merely reduce the appliance’s efficiency.
5. If in the course of operation the pulp container (4) (4) (4) (4) (4) becomes full,
switch off the juice extractor, disassemble it and clean the con-
tainer from pulp. Assemble the appliance to continue operation.
6. After you finish, immediately wash the juice extractor and thor-
oughly dry its parts.
CARE AND CLEANING
1. Unplug the juice extractor from the electrical
outlet and disassemble it (see «Disassembly»).
2. Wipe the appliance body with soft damp cloth.
Never immerse the appliance body Never immerse the appliance body Never immerse the appliance body Never immerse the appliance body Never immerse the appliance body
and power cord in water or any other and power cord in water or any other and power cord in water or any other and power cord in water or any other and power cord in water or any other
l i q u i d l i q u i d l i q u i d l i q u i d l i q u i d .....
3. Wash the remaining parts of the juice ex-
tractor in soapy water with a soft sponge. Do not use stiff brushes
and abrasive cleaners. The lid, separating unit, grater/filter,
pulp container are dishwasher-safe.
4. When extracting juice from such food as carrots, etc. the plastic
parts of the juice extractor coming into contact with food may
become stained. To clean the stains, wipe the parts with cloth
moistened with a small amount of vinegar diluted by water –
two or three teaspoonfuls of 9% vinegar per a glass of water –
then wash the parts as usual.
