ENGLISH
3
CLOCK RADIO WITH NIGHT LIGHT
LOCATION OF CONTROLS
1. ON/OFF/AUTO Function selector
2. Display
3. Battery compartment
4. Radio frequency scale
5. Radio frequency tuning knob
6. Band selector
7. VOLUME/BUZZER knob
8. SNOOZE button
9. SLEEP button
10. MINUTE setting button
11. CLOCK setting button
12. HOUR setting button
13. “On/Off” switch for lamp
14. ALARM button
POWER
1. Connect the power cord to the outlet.
Make sure that the voltage indicated on
the device matches the voltage in your
home.
2. Place one 9 V battery (not included) into
the battery compartment (3). The bat-
tery maintains the clock in case of power
failure. In such cases, the display will not
work, but the time is being maintained.
After long use, the battery can go bad
and leak. If you use the unit without a
battery, then you will be required to set
the time, as instructed in the “Time Set-
ting” section, each time the unit is dis-
connected from power.
TURNING ON THE LIGHTING
1. Connect the
power cord to the
outlet.
2. Lift the body of
the clock up from the
sides until it stops.
3. Tighten the cen-
tral bolts holding the
body to the lamp,
as shown in the dia-
gram.
4. Set the lighting switch (13) to the ON po-
sition.
Note: Do not forget to set the lighting
switch (13) to the OFF position before in-
stalling the lamp shade. Make sure the light
bulb has cooled before changing. Remove
the old light bulb and install a new one (25
Wt bulb).
SETTING THE CURRENT TIME
Press and hold the TIME button (11), set the
hours by pressing the HOUR (12) button
and the minutes by pressing the MINUTE
button (10). The current time will be shown
on the display (2).
RADIO
1. Set the function selector (1) to the ON
position.
2. Set the band selector (6) to the FM1 or
FM2 position.
3. Set the radio to the desired broadcasting
station using the TUNING knob (5).
4. Adjust the volume using the VOLUME
knob (7).
5. Extend the antenna wire fully in order to
achieve the best FM reception.
WAKING UP TO MUSIC
1. Set the function selector (1) to the ON
position.
2. Set the band selector (6) to the FM1 or
FM2 position.
3. Set the desired station using the TUN-
ING knob (5).
4. Set the desired volume (7).
5. Set the function selector (1) to the AUTO
position.
6. Press and hold the ALARM button (14),
set the hours (12) and minutes (10), us-
ing the appropriate buttons.
7. In order to verify that the correct time has
been set, press the ALARM button (14).
The set time will be saved to the device’s
memory and the radio will turn on every
day at the same time.
