Instruction manual Instruction manual
Dear customer!
Thank you for purchasing our product. For safety, it is strongly recommended to read
this manual carefully before connecting, operating and/or adjusting the product and keep
the manual for reference in future.
Description
1. BAND button
2. TEMP/
button
3. Y-M-D/ button
4. AL.1 button
5. DIMMER switch
6. SNOOZE/SLEEP button
7. LIGHT switch
8. AL.2 button
9. AL.SET button
10. MODE button
11. button
Important safeguards
• The instruction manual contains important
operating and maintenance instructions. For
your safety, it is necessary to refer the manual.
Keep the manual for use in future.
• Do not hit or drop the unit.
• Do not expose the unit to vibration,
direct sunlight, too high or low temperature or
humidity.
• If you are not going to use the unit within
a long period of time, remove the batteries to
avoid their leakage.
• Do not disassemble the unit yourselves.
Refer servicing to qualified service personnel.
Power supply
Battery operation
• Insert 1 x 3 V lithium battery CR2032 (not
included) to the terminal inside the battery
compartment according to the polarity marks (+
and -). Your set will not work normally from the
battery supply, but there is now the advantage
that, in case there is a mains current failure,
your clock will continue to work. The clock
display will not light up, the clock time and
alarm setting will be held in the clock memory
by the battery back-up system.
This enables you to move the set from place to
place without re-setting the clock every time. The
battery back-up system is only meant to be used
from short temporary power failures. For longer
1 2 3 4 5 6 7 8 9 10 11
Not indicated: power cord (back panel), FM antenna (back panel), temperature sensor (back
panel), line input (back panel), battery compartment (bottom), TUNER regulator (right panel),
VOLUME regulator (right panel), RESET button hole (left panel), display (front panel).
