Cordless drill ENG
increase and the drill will have less power and
torque.
Warning: To prevent gear damage,
always allow the chuck to come
to a complete stop before changing the
direction of rotation or the two-speed
gear train.
10. CHUCK ADJUSTMENT
Adjusting the chuck is easy with your WORX
drill as it is fitted with spindle lock.
To open the chuck jaws rotate the front section
of the chuck. Insert the drill bit between the
chuck jaws and rotate the front section in the
opposite direction. Ensure the drill bit is in the
center of the chuck jaws. Finally, firmly rotate
the front chuck section in opposite directions.
Your drill is now clamped in the chuck.
11. TORQUE ADJUSTMENT
(Screw driving force of your drill driver)
The torque is adjusted by rotating the torque
adjustment ring (See E). The torque is greater
when the torque adjustment ring is set on a
higher setting. The torque is less when the
torque adjustment ring is set on a lower setting.
Rotate the adjustment ring to the desired
setting:
1 - 4
for driving small screws
5 - 9 for driving screws into soft material
10 - 14 for driving screws into soft and hard
material
15 - 19 for driving screws into hard wood
20 - 23 for driving larger screws
24
for heavy drilling
12. BIT STORAGE
The bits provided with the drill can be placed in
the storage area located at the side of the drill,
slide in and out. (See F).
13.LEVEL DRILLING
The bubble level (12) is recessed in the motor
housing of your drill-driver on top. It can be
used to keep drill bits level during horizontal
drilling operation (See G).
14. DRILLING
When drilling hard smooth surface, use a
center punch to mark the desired hole location.
This will prevent the drill bit from slipping
off center as the hole is started. Hold the tool
firmly and place the tip of the bit at the point
to be drilled. Depress the switch trigger to start
the tool. Move the drill bit into the workpiece,
applying only enough pressure to keep the bit
cutting. Do not force or apply side pressure to
elongate a hole.
Tungsten carbide drill bits should
always be used for concrete and
masonry. When drilling in metal, only use
HSS drill bits in good condition. Always
use a magnetic bit holder when using
short screwdriver bits. When screw-
driving, apply a small quantity of liquid
soap or similar to the screw threads to
ease insertion.
15. DISPOSAL OF AN EXHAUSTED
BATTERY PACK
To preserve natural resources, please
recycle or dispose of the battery pack
properly. This battery pack contains NI-Cd or Ni-
Mh batteries. Consult your local waste authority
for information regarding available recycling
and/or disposal options. Discharge your battery
pack by operating your drill, then remove the
battery pack from the drill housing and cover
the battery pack connections with heavy duty
adhesive tape to prevent short circuit and
energy discharge. Do not attempt to open or
remove any of the components.
16. AUTOMATIC SPINDLE LOCK
The automatic spindle lock allows you to
use as a regular screwdriver. You can give an
extra twist to firmly tighten a screw, loosen
a very tight screw or continue working when
the battery energy has expired (See H). For
manual screwdriver purposes, the chuck is
automatically locked when the tool is off.
PROBLEM SOLUTION
1. WHY DOES THE DRILL NOT TURN ON
WHEN YOU PRESS THE SWITCH?
The forward and reverse switch, which is on top
of the trigger, is positioned in the lock function.
Unlock the forward and reverse switch putting
