Finishing sander ENG
SYMBOLS
Read the manual
Warning
Wear eye protection
Double insulation
Wear ear protection
Wear dust mask
OPERATING INSTRUCTIONS
1. ON /OFF SWITCH
Depress to start and release to stop your tool.
2. SWITCH LOCK-ON BUTTON
Depress on/off switch (1) then lock-on button
(2)(See A), release on/off switch first and lock-
on button second. Your switch is now locked on
for continuous use. To switch off your sander
just depress and release the on/off switch.
3. VARIABLE SPEED CONTROL DIAL
Adjust the dial (3) to increase or decrease the
speed according to the material and sanding
sheet specification to be used (also possible
during no load operation) (See A). See the table
below for general guidance on speed selection.
Avoid prolonged use at very low speed as this
may damage your sander’s motor.
4. HAND GRIP AREA
You can operate your sander with two hands
(See B).
5. CHANGING STANDARD SANDING
PAPER
To remove the sanding paper, lift up the clamp
lever and move away from the clamp lever
lock (See C.1). The sanding paper clamp is
now loose. Repeat with the other clamp on the
opposite side of your sander. To fit new sanding
paper, insert approximately 5mm of one end
of the sanding paper under the sanding paper
clamp until the paper contacts the housing wall
(See C.2). Lift up the clamp lever and move it to
Sanding work
Grain
Speed
setting(opm) Coarse
sanding
Precision
sanding
Sanding down varnishes 180 400 8700~12000
Stripping paint 40 120 9800~12000
Touching up paintwork 120 120 7600~10000
Sanding wood 60 240 7600~12000
Machining veneer 180 400 8700~11000
Sanding aluminium 80 240 7600~11000
Derusting metal 40 120 9800~12000
Sanding metal and steel 120 240 9800~12000
Sanding plexiglass 180 400 6500~8700
