3
Car power supply unit, stabilized
• Input: 14 V direct current, max.
• Output: 1.5–3.0–4.5–6.0–7.5–9 V stabilized/12 V
• Output current: 2000 mA, max.
• Supplied with a total of 8 plugs: 2 jack plugs – 2.5 mm and 3.5 mm
6 DC plugs 0.75 x 2.4/1.0 x 3.0/1.3 x 3.5/1.7 x 4.0/2.1 x 5.0/2.5 x 5.5 mm
• Reversible polarity
• LED check light
• CE- and e-certifi ed
Important:
Please observe the correct voltage and polarity setting and the corresponding instructions
from the device manufacturers. We are not liable for damage caused by incorrect voltage
selection or false polarity. Always disconnect the power supply unit from the power source
(e.g. cigarette lighter socket) when setting the voltage or polarity! The cigarette lighter plug
contains a fuse which will be blown by a short circuit or false polarity. This fuse must only be
replaced with one of equal rating. The red LED indicates safe contact with the power source.
• Protect the device from all moisture.
• Repairs must only be carried out by an authorized specialist.
• Only clean with a dry cloth.
• Keep well out of the reach of children, as is the case with all electrical appliances!
g Operating Instructions
oben/
topside
Plusschaltung/Centre Pin +
Minusschaltung/Centre Pin -
