PARTS LIST: Outfeed Table Assembly (PJ1696 Jointer)
Index Part No.
No. Description Size Qty.
I .........PJ1696-601 ...............Outfeed Table Lip..........................................................................1
2.........PJ1696-602................Outfeed Table...................................................................... ........1
3.........TS-1505061................Socket Head Cap Screw...............M10 x 40.....................................4
4.........PJ 1696-603...............Table Lifting Support Base..............................................................1
5.........PJ1696-604................Table Raising Link Bar....................................................................2
6.........PJ1696-605................Bushing.......................................................................................8
7.........PJ 1696-606...............Pivot Shaft...................................................................................6
8.........PJ1696-607................Adjustment Shaft..........................................................................2
9....... TS-1525031............ Socket Set Screw........................M10x16.......................... ............8
10.......PJ 1696-608................Table Lifting Spring.......................................................................2
11 .......PJ 1696-609................Hanger.......................................................................................2
12.......TS-0570011................ Hex Nut.......................................1/4-20............................ ……..4
Outfeed Table Assembly (PJ1696 Jointer)
