Инструкция по эксплуатации Hisense AF-24ER4SL
Страница 6
Model
AS-07HR4SVNNT
AS-09HR4SVNNT4
AS-12HR4SVNNT1
AS-18HR4SWVNT
AS-24HR4SFJNT
Indoor unit
AS-07HR4SVNNT
AS-09HR4SVNNT4
AS-12HR4SVNNT1
AS-18HR4SWVNT
AS-24HR4SFJNT
Outdoor unit
AS-07HR4SVNNT-O1 AS-09HR4SVNNT4-O1 AS-12HR4SVNNT1-O1 AS-18HR4SWVNT-O1
AS-24HR4SFJNT-O1
Capacity (cooling) BTU (kW)
7000 (2,1)
9000 (2,5)
12000 (3,2)
18000 (5,0)
24000 (6,5)
Capacity (heating) BTU (kW)
7500 (2,2)
9000 (2,6)
12000 (3,2)
18000 (5,1)
25000 (6,8)
Rated input (cooling) W
655
779
997
1558
2025
Rated input (heating) W
610
706
886
1413
1884
Voltage V/Hz
220/50
220/50
220/50
220/50
220/50
Rated current (cooling/heat ing) A
2,9/2,7
3,5/3,2
4,4/3,9
7,1/7,0
10,1/ 10,0
Air circulat ion (indoor unit) m3/h
460
480
540
800
960
Air circulat ion (outdoor unit) m3/h
1600
1600
1600
1850
2300
Noise level (indoor unit) dB(A)
32-37
32-37
35-40
41-46
45-50
Noise level (outdoor unit) dB(A)
53
53
55
58
58
Refrigerant
R410A
R410A
R410A
R410A
R410A
Energy class (cooling/ heating)
A/A
A/A
A/A
A/A
A/A
Electrical protection class
I класс
I класс
I класс
I класс
I класс
Degree of protection against moisture (indoor unit)
IPX0
IPX0
IPX0
IPX0
IPX0
Degree of protection against moisture (outdoor unit)
IPX4
IPX4
IPX4
IPX4
IPX4
Refrigerant piping, Liquid side / Gas side, (inch)
1/4 / 3/8
1/4 / 3/8
1/4 / 1/2
1/4 / 1/2
3/8 / 5/8
Max. refrigerant pipe length, m
15
15
15
15
15
Maximum difference in level, m
5
5
5
5
5
Net weight, indoor unit (kg)
7,0
7,0
8,0
11,0
13,0
Net weight, outdoor unit (kg)
23,0
26,0
27,0
36,0
54,0
Net dimensions, indoor unit (mm)
790x262x195
790x262x195
790x262x195
975x325x228
1078x325x230
Net dimensions, outdoor unit (mm)
715x482x240
715x482x240
715x482x240
760x545x255
830x637x285
