Hyundai H-1511 - Инструкция (Страница 2)

2 3
Instruction manual Instruction manual
Dear customer!
Thank you for purchasing our product. For safety, it is strongly recommended to read
this manual carefully before connecting, operating and/or adjusting the product and keep
the manual for reference in future.
Description
1. FOCUS regulator
2. PROJECTION switch
3. ALARM button
4. SLEEP button
5. HOUR button
6. MIN button
7. SNOOZE button
8. TIME button
9. Display
10. VOLUME regulator
11. Dial scale
12. TUNING regulator
13. ALARM/ON/OFF/AUTO button
14. AM/FM band switch
Not indicated: battery compartment (back
panel)
Important safeguards
• The instruction manual contains important
operating and maintenance instructions. For
your safety, it is necessary to refer the manual.
Keep the manual for use in future.
• Do not hit or drop the unit.
• Do not expose the unit to vibration,
direct sunlight, too high or low temperature or
humidity.
• If you are not going to use the unit within
a long period of time, remove the batteries to
avoid their leakage.
• Do not disassemble the unit yourselves.
Refer servicing to qualified service personnel.
Power supply
Battery operation
• Insert 1x9V battery (not included) to the
terminal inside the battery compartment. Your
set will not work normally from the battery
supply, but there is now the advantage that, in
case there is a mains current failure, your clock
will continue to work. The clock display will not
light up, the clock time will be held in the clock
memory by the battery back-up system.
This enables you to move the set from place
to place without re-setting the clock every time.
The battery back-up system is only meant to
be used from short temporary power failures.
For longer durations the battery may become
1
2
3
4
5
6
7
8
9
10
11
12
13
14
