DESCRIPTION
1. Snooze button
2. Alarm set button
3. Time set button
4. Sleep set button
5. Hour set button
6. Minute set button
7. On/Off/Auto/Alarm selector
8. Tuning control
9. Volume control
10. FM antenna
11. Auto indicator
12. Main plug (AC cord)
13. Alarm off button
14. AM/FM selector
15. Battery back-up
16. Display
SAFETY MANUAL
Lightning mark
The lightning flash
within the triangle
is a warning sign
alerting you of
“dangerous voltage”
inside the product
CAUTION
Risk of electric shock!
DO NOT OPEN
Exclamation mark
The exclamation point
within the triangle is a
warning sign alerting
you
of important
instructions
accompanying the
product
1. Study the manual. It’s necessary to study all the points of safety manual.
2. Keep the safety of manual for future use.
3. Check whether the electricity supply in the sockets corresponds to the voltage of the unit.
4. Do not use the unit near water such us bathtub, wash bowl, kitchen sink, laundry tub or wet
basement.
5. Do not overload wall outlets or extension cords as this can result in a risk of fire or electric shock.
6. For additional safety during lighting, switch off the unit from the plug.
7. In case you are not going to use the unit for along time, remove the batteries to avoid their
leakage.
8. Do not remove the cover of the unit yourself. Technical maintenance should be performed only by
qualified service personnel.
9. Keep the unit away from heat sources, such as heat registers, radiators, stoves etc.
POWER OPERATION
Battery operation
• Insert 1x9В battery into battery compartment; preferably to use long-life batteries. In case of
temporary power failure, the battery will store time settings, even if time will not be shown on
display.
Note: The affectivity of this feature totally depends on battery charge. Otherwise if the battery is old
or of bad quality, the unit will not show correct time.
AC operation
• Before the connection of the unit, check that voltage indicated in the list of technical characteristics
corresponds to mains voltage in your home.
Clock Setting
Set button On/Off/Auto/Alarm Switch (7) to Off. Connect the Mains Lead to the power supply.
The clock display will flash on and off indicating a power interruption and that the display time is
incorrect..
To set the correct time, press the Time Set Button(3) and Minute Set Button (6), or Hour
Set Button (5), together, until the correct time is displayed.
Note: Open the Clock Battery Compartment door and fit a PP3 (or equivalent) 9V battery. The
purpose of this battery is to store the information relating to alarm time, and to keep the clock
functioning in the event of disconnection from the mains supply or power interruption. Should this
occur, the clock will continue to keep time, but will not display.
Alarm Setting
To set the alarm time, press the Alarm Set Button (2) and Minute Set Button (6), or Hour Set Button
(5), together, until the required alarm time is displayed.
Switch the On/Off/Auto/Alarm Switch (7) to either ‘AUTO’ or ‘ALARM’ position for choice of wake by
radio or wake by buzzer respectively. The Auto Indicator (11) will illuminate and alarm is now set to
activate at the required time.
The alarm can be temporarily stopped for 9 minutes by pressing the Snooze/Sleep Off Button (1).
This can be repeated until press the Alarm Button (2).
The alarm will activate again after 24 hours unless the On/Off/Auto/Alarm Switch (7) is set to ‘OFF’.
Note: When setting alarm time always remember to release the Minute Set or Hour Set or Hour Set
Button before releasing the Alarm Set Button to ensure that the real time will not be affected
Sleep Setting
Set the On/Off/Auto/Alarm Switch (7) to ‘OFF’, ‘AUTO’ or ‘ALARM’ position.
Press the Sleep Set Button (4) and Minute Set Button (6) together. The sleep time will be displayed
and count down from 59 minutes to zero. Release the button when the required sleep time is
displayed.
The radio will now operate until the sleep time has elapsed or may be switched off by pressing the
Snooze Off Button (1).
Radio Setting
The FM band required the use of the FM aerial wire, this should be uncoiled and positioned for best
reception. Set the On/Off/Auto/Alarm Switch (7) to ‘ON’ position.
Adjust the Tuning Control (8) to select the desired station.
Adjust the Volume Control (9) as required.
To turn off the radio, set the On/Off/Auto/Alarm Switch (7) to ‘OFF’. If the radio does not switch off
this may be caused by inadvertent operation of the Sleep Set Button (4). To cancel this presses the
Snooze/Sleep Off Button (1) once.
Adjust the Switch (14) to the required waveband.
Clean and Care
Clean the cabinet with a soft cloth moistened with water or mild detergent. Do not use solvents such
as alcohol, benzene or thinner, as the may damage the cabinet finish. Make sure to disconnect the
mains lead from the supply before cleaning. Please retain these instructions for future reference.
Technical Characteristics
Frequency range: AM 530-1600 KHz
FM 64-108 MHz
Power source: AC 220V, 50Hz
DC 9V
Power output: 300mW
Stabilizer: Quarts
Display: 0,9”
