Attaching the Presser Foot Shank
22
Raise the presser bar
dge/ quilting
dge/ quilting
foot (a) with the presser foot lifter.
Attach the presser foot shank (b) as illustrated. (1)
Lower the presser foot shank (b) using the presser foot lifter,
until the cut-out (c) is directly above the pin (d). (2) The
presser foot (f) will engage automatically.
Raise the presser foot using the presser foot lifter. (3)
Raise the lever (e) and the foot disengages.
Attach the e guide (g) in the slot as illustrated.
Adjust as needed for hems, pleats, quilting, etc. (4)
Turn power switch to off ("O") when carrying out any of
the above operations!
Attaching the presser foot
Removing the presser foot
Attaching the e guide
Attention:
