8
When using the Euro-AV connector plug
Connect your PlayStation
®
2 console to the Euro-AV connector (SCART) on the TV using the Euro-AV connector plug and AV cable, making sure you match the colour-coded
plugs of the AV cable to the matching jacks of the connector plug.
To Euro-AV connector
To AV MULTI OUT connector
Euro-AV connector plug
AV cable
TV
