16
Specifications
Additional Information
TV system:
B/G/H, D/K
Colour system:
PAL, SECAM
NTSC 3.58, 4.43 (only Video In)
Channel Coverage:
VHF: E2-E12
UHF: E21-E69
CATV: S1-S20
HYPER: S21-S41
D/K: R1-R12,
R21-R69
Picture Tube:
Flat Display FD Trinitron
Rear Terminals
:1/ 21-pin scart connector
(CENELEC standard)
including audio/video
input, RGB input, TV audio/
video output.
Front Terminals
…2 video input – phono jack
2 audio input – phono jack
headphones jack
Sound Output:
1 x 6 W (music power)
1 x 3 W (RMS Mono)
Design and specifications are subject to change without notice.
Ecological Paper- Totally Chlorine Free
Power Consumption:
42 W
Standby Power Consumption:
≤ 0.55 W
Dimensions (w x h x d) :
Approx. 393 x 358 x 415 mm.
Weight:
Approx. 11.5 Kg.
Accessories supplied:
1 Remote Control (RM-889).
2 Batteries (IEC designated).
1 Aerial.
Other features:
• Sleep Timer.
• Wake UP Timer.
• TV system Autodetection.
03GBKV14LM1K.fm Page 16 Friday, June 22, 2001 11:46 AM
