ENGLISH
Adjusting the sound
You can adjust the sound characteristics to your
preference.
1
Ex.: When “TRE” is selected
2
Indication pattern changes as
you adjust the level.
Indication To do: Range
BAS* 1
(bass)
Adjust the bass. –06 (min.)
to
+06 (max.)
TRE* 1
(treble)
Adjust the treble. –06 (min.)
to
+06 (max.)
FAD* 2
(fader)
Adjust the front
and rear speaker
balance. R06
(Rear only)
to
F06
(Front only)
BAL
(balance) Adjust the left
and right speaker
balance. L06
(Left only)
to
R06
(Right only)
LOUD* 1
(loudness)
Boost low and
high frequencies
to produce a
well-balanced
sound at low
volume level. LOUD ON
J
LOUD OFF
SUB. W* 3
(subwoofer)
Adjust the
subwoofer output
level. 00 (min.)
to
08 (max.)
VOL* 4
(volume)
Adjust the
volume. 00 (min.)
to
30 or 50
(max.)*
5
* 1 When you adjust the bass, treble, or
loudness, the adjustment you have made is
stored for the currently selected sound mode
(C-EQ) including “USER.”
* 2 If you are using a two-speaker system, set
the fader level to “00.”
* 3 This takes effect only when a subwoofer is
connected.
* 4 Normally the control dial works as the
volume control. So you do not have to select
“VOL” to adjust the volume level.
* 5 Depending on the amplifier gain control
setting. (See page 24 for details.)
