SoundMax SM-CMD3000 - Инструкция (Страница 21)

• Open session discs are NOT supported.
USB/SD/MMC notes
USB functions (flash memory type) MP3 music play.
1. SD/ MMC card support, 2in1 (SD/ MMC) support.
2. USB flash memory.
3. FAT 12/ FAT 16/ FAT 32 is possible
- FAT 12/16 (dir: 200 support, file: 500 support),
- FAT 32 (dir: 200 support, file: 500 support).
4. Filename: 32 byte/ Dir name: 32 byte.
5. Tag (id3tag ver. 1.0)
- Title/ Artist/ Album: 32 byte support.
6. Multi card reader not support.
7. USB 2.0 support.
Note:
USB format supports 2.0.
Capacity: 8 MB ~ 1 GB.
SD cards brands: Cannon, Fuji film, Palm, Motorola, Microsoft, IBM, HP, Compaq, Sharp, Samsung, etc.
Capacity: 8 MB ~ 1 GB.
MMC cards brands: Ericsson, Nokia, Motorola, HP, Palm, Sanyo, Microsystems, etc.
Capacity: 16 MB ~ 1 GB.
Loading a disc
1. Turn the power on.
2. Press the EJECT button on the panel to flip it down. Insert the disc with the printed side facing upward
into the slot. Press EJECT button on the panel to eject the disc. The panel will be closed automatically.
3. Playback will start automatically.
Inserting the SD/ MMC card/ USB device
Press EJECT button and SD/MMC slot will be available under the front panel.
Insert the MMC/ SD card or USB device into MMC/ SD compartment or USB socket.
Then the playing mode will be changed into MMC/ SD or USB mode automatically.
The first card/ USB device track playback will start.
21
