ENGLISH
Storing your own sound
adjustments
You can adjust the sound modes to your
preference and store your own adjustments in
memory (USER 1, USER 2 and USER 3).
• There is a time limit in doing the following
procedure. If the setting is canceled before you
finish, start from step
1 again.
1
Press MODE to enter the functions
mode.
2
Press EQ (equalizer) while “MODE”
is still on the display.
The last selected sound mode
is called up.
3
Select the sound mode you want to
adjust.
4
Select sound elements to adjust.
Each time you press the
button, the sound elements
change as follows:
LOW LEVEL* = LOW FREQ = LOW WIDTH
= MID LEVEL* = MID WIDTH
= HI (high) LEVEL* = HI (high) FREQ
= (back to the beginning)
LEVEL (LOW, MID, HI):
Adjust the enhancement level.
* By pressing ¢ or 4 , you can
directly move as follows:
FREQ (LOW, HI):
Select the center frequency to adjust.
WIDTH (LOW, MID):
Select the band width level.
5
Adjust the selected sound element.
Indication
Preset values
LOW MID HI
LEVEL –06 (min.) –06 (min.) –06 (min.)
| | |
+06 (max.) +06 (max.) +06 (max.)
FREQ. 60Hz 8kHz
80Hz 10kHz
100Hz 12kHz
120Hz 15kHz
WIDTH 1 (min.) 1 (min.)
| |
4 (max.) 2 (max.)
6
Repeat steps 4 and 5 to adjust the
other sound elements.
7
Select one of the user sound modes
(USER 1, USER 2, USER 3).
8
Press EQ to store the adjustments.
“MEMORY” appears for a
while.
Ex.: When you select “JAZZ”
LOW LEVEL MID LEVEL
HI LEVEL
