ENGLISH

33

3

Start searching an ensemble.

When an ensemble is received, searching
stops.

To stop searching before an ensemble is
received,
press the same button you have
pressed for searching.

4

Select a service you want to listen to.

Press

5

(up) to select the

next service.

Press

¢

to

search ensembles of
higher frequencies.

Press

4

to

search ensembles of
lower frequencies.

Press

(down) to select

the previous service.

To change the display information while
tuning in to an ensemble

Normally service name is shown on the display.
If you want to change the display information,
press DISP.

Each time you press the button, the
following information appears on the
display for a while.

To tune in to a particular ensemble
without searching:

1 Press and hold DAB (FM AM) to select DAB

tuner as the source.

2 Press DAB (FM AM) repeatedly to select the

DAB band (DAB1, DAB2 or DAB3).

3 Press and hold

¢

or

4

for more

than 1 second.

4 Press

¢

or

4

repeatedly until the

ensemble you want is selected.
• If you hold down the button, the frequency

keeps changing until you release the button.

To restore the FM/AM tuner

Press and hold DAB (FM AM) again.

Ensemble name

Service name

Channel number

Frequency
