8
ENGLISH
MONITOR CONTROL
1 Monitor control buttons
• Used for a JVC monitor—KV-MR9010,
or KV-MH6510.
DVD/RECEIVER CONTROL
2 • Turns on the power.
• Attenuates the sound if the power is on.
• Turns off the power if pressed and held
(while the power is on).
3 Selects the source.
4 Selects the FM/AM/DAB bands.
5 Changes the aspect ratio of the playback
pictures.
6 Activates or deactivates Dual Zone.
7 Adjusts the volume level.
• Also functions as 2nd VOL when
pressed with SHIFT button (☞ page 26).
8* 1 • DVD/DivX 6: Shows the disc menu.
• VCD: Resumes PBC playback
(☞ page 21).
9* 1 Not used as SETUP button for this
receiver.
p SHIFT button
Basic operations —
Remote controller (RM-RK240)
Installing the lithium coin battery (CR2025)
Before using the remote controller:
• Aim the remote controller directly at the
remote sensor on the unit.
• DO NOT expose the remote sensor to bright
light (direct sunlight or artificial lighting).
The receiver is equipped with the steering
wheel remote control function.
• See the Installation/Connection Manual
(separate volume) for connection.
Warning:
To prevent accidents and damage
• Do not install any battery other than
CR2025 or its equivalent.
• Store the battery in a place where children
cannot reach.
• Do not recharge, short, disassemble, or
heat the battery or dispose of it in a fire.
• Do not leave the battery with other
metallic materials.
• Do not poke the battery with tweezers or
similar tools.
• Wrap the battery with tape and insulate
when throwing away or saving it.
IMPORTANT:
If Dual Zone is activated (☞ page 26),
the remote controller functions only for
operating the DVD/CD player.
Main elements and features
MODE MENU ASPECT
ZOOM ATT
SOURCE
DISC+
DISC–
DVD / RECEIVER CONTROL
EXTRA MONITOR CONTROL
+10
–10
1 2 3
4 5 6
7 8
0
9
–100
BAND
OSD
MENU TOP M
SETUP RETURN
ENTER
DUAL
SHIFT
VOL
2nd VOL
+100
DIRECT
ASPECT
SURROUND
