39
ENGLISH
○ ○ ○ ○ ○ ○ ○ ○ ○
Adjusting AV OUTPUT volume
Select an appropriate volume level for the
component connected to the AV OUTPUT
jacks on the hideaway unit.
• This functions without respect to the Dual
Mode setting.
1
2
3
4
Adjust the AV output volume.
When using the remote controller:
• For Dual Mode operations...
– When controlling the monitor connected
to the AV OUTPUT jacks, aim the
remote controller at the remote sensor
on the main unit.
– When controlling the monitor inserted
into the cradle, aim the remote controller
at the remote sensor on the cradle.
To activate Dual Mode
Each time you press and hold the button,
Dual Mode turns on and off.
• When Dual Mode is turned on, the source
selection screen appears on the monitor
(see page 38).
To operate the subsidiary source
1
2 Press the source buttons, then the
source operation buttons.
To operate the main source
1
2 Press the source buttons, then the
source operation buttons.
ZOOM
DUAL
Hold
MAIN SUB
AVOUT VOL
On the remote controller
then
MAIN SUB
MAIN SUB
* 2
* 1 * 1
* 1 It does not appear for some sources.
* 2 It will be shaded when not available.
While Dual Mode is in use...
• The playback source does not change to
“DISC” though you insert a disc. “DUAL”
flashes on the display of the main unit.
• You can only adjust the volume level for
the subsidiary source (the other sound
adjustments cannot be used for the
subsidiary source).
