Zanussi ZOB593 - Инструкция (Страница 32)

Shelf Support Rails
Removing the shelf support rails
1 Pull the front of the
shelf support rail away
from the side wall.
1
2
2 Pull the rear shelf sup-
port rail away from the
side wall and remove it.
Installing the shelf support rails
Install the shelf support rails in opposite sequence.
The rounded ends of the shelf support rails must
point to the front!
Oven ceiling
You can remove the heating element on the oven ceiling
to clean the oven ceiling easily.
Warning! Before you remove the heating element
switch off the appliance. Make sure that the
appliance is cold. There is a risk of burns!
1 Unscrew the screw
which holds the heating
element. For the first time,
use a screwdriver.
2 Carefully pull the heat-
ing element downwards.
The oven ceiling is ready
to clean.
Clean the oven ceiling with a soft cloth with warm water
and cleaning agent and let it dry.
Installing the heating element
1. Install the heating element in opposite sequence.
Warning! Make sure that the heating element is
correctly installed and it does not fall down.
Oven lamp
Warning! Be careful! There is the risk of electrical
shock!
Before you change the oven lamp:
• Switch off the oven.
• Remove the fuses in the fuse box or switch off the cir-
cuit breaker.
Put a cloth on the bottom of the oven for protection
of the oven light and glass cover.
1. Turn the glass cover anti-clockwise to remove it.
2. Clean the glass cover.
3. Replace the oven light bulb with applicable 300°C
heat-resistant oven light bulb.
Use the same oven lamp type.
4. Install the glass cover.
Cleaning the oven door
The oven door has two panels of glass. You can remove
the oven door and the internal panel of glass to clean it.
The oven door can close if you try to remove the in-
ternal panel of glass before you remove the oven
door.
1 Open the door fully
and hold the two door
hinges.
2 Lift and turn the levers
on the two hinges.
32
