EN
12
5
Using your refrigerator
There are three coloured indicator lights
located on the front of the appliance
which shows the operating mode of
the freezer.
Green Indicator
(1):
Illuminates
when the appliance is connected to
the mains and will glow as long as
electricity is available. The green light
will not glow if the thermostat is set
to ‘0’ position. The green indicator
does not give any indication of the
temperature inside the freezer.
Amber Indicator
(2):
This indicator will
glow when the fast freeze switch is
on and will continue to glow until the
fast freeze switch is turned off. The
compressor will run continuously while
fast freeze switch is on. Fast freeze
operation is for freezing fresh food.
Red Indicator (3) Illuminates:
a
) If the pre-set temperature can not
be maintained.
b
) If excessive amounts of fresh food
are placed inside.
c
) If the appliance door is left open
accidentally.
4
2
3
1
5
Thermostat knob (5)
Thermostat knob
is located on the indicator light set.
IMPORTANT:
When you press the fast
freeze switch, there may be a short
delay before the compressor starts to
operate. This is normal and does not
indicate a compressor fault.
LED indicators and control
panel
