Indesit K 1G210 - Инструкция (Страница 8)

8
GB
A
S
Grill
To light the grill, bring a flame or gas lighter close to
the burner and press the OVEN control knob while
turning it in a clockwise direction until it reaches the
d position. The grill enables the surface of food to be
browned evenly and is particularly suitable for roast
dishes, schnitzel and sausages. Place the rack in
position 4 or 5 and the dripping pan in position 1 to
collect fat and prevent the formation of smoke.
! The grill is fitted with a safety device and it is
therefore necessary to hold the OVEN control knob
down for approximately 6 seconds.
! If the flame is accidentally extinguished, switch off the
burner and wait for at least 1 minute before attempting
to relight the grill.
! When using the grill, leave the oven door ajar,
positioning the deflector D between the door and the
control panel (see fi gure) in order to prevent the knobs
from overheating.
Oven light
The light may be switched on
at any moment by pressing the
OVEN LIGHT button.
Timer
To activate the Timer proceed as follows:
1. Turn the TIMER knob in a clockwise direction
4 for
almost one complete revolution to set the buzzer.
2. Turn the TIMER knob in an anticlockwise direction
5
to set the desired length of time.
Lower compartment
There is a compartment
underneath the oven
that may be used to
store oven accessories
or deep dishes. To
open the door pull it
downwards (see fi gure).
! The internal surfaces of the compartment (where
present) may become hot.
! Do not place flammable materials in the lower oven
compartment.
In gas cooker models, there is
a sliding protection layer A that
shields the lower compartment
from the heat generated by the
burner (see fi gure).
To remove the sliding
protection remove the screw S
(see fi gure). To replace it, lock it
in place with the screw S.
! Before using the oven make
sure that the sliding protection
is fixed correctly.
D
