STEREO RADIO CASSETTE RECORDER

RQ-SX97F

Operating Instructions

л^g

Инструкция по эксплуатации

Before connecting, operating or adjusting this product, please read these
instructions completely. Please keep this manual for future reference.

GCS

GK

GH

SG

Matsushita Electric Industrial Co., Ltd.

Osaka 542-8588, Japan

En; ,Cn,' ;Co; (Ko) (R

uj

RQTT0401-G

F0301KBO

Specifications

■ RADIO
Frequency range:

AM MODE

AM (kHz)

FM (MHz)

9 kHz mode

522-1629

87.50-108.00

10 kHz mode

520-1630

87.50-108.00

■ CASSETTE PLAYER/RECORDER
Track system:
Recording system:

Erasing system:
Monitor system:
Frequency range:

Playback

(Normal/High/Metal);

Recording (Normal);

■ GENERAL
Input jack;

Output jack:
Power output:
Power requirement:

Rechargeable battery;
Battery;

Dimensions (WXHXD):
Mass:
■ CHARGER

Input;

4 track, 2 channel, stereo
AC bias

DC erase
Variable sound monitor

40-18000 Hz (-6 dB)
80-8000 Hz(-6dB)

MIC; 0.56 mV (200-600 Q)
PHONES; 80 Q
1.8 mW+1.8 mW (RMS...max.)

DC 1.2 V (included rechargeable battery)
DC 1.5 V (one R6/LR6, AA, UM-3 battery)
108.8x77.2x20.7 mm
167 g (with rechargeabie battery)

(For China) AC 220 V, 50 Hz, 4 W
(For Hong Kong) AC 220-240 V, 50 Hz, 4 W
(For Others) AC 220-230 V, 50 Hz, 4 W

Output:

DC 350 mA, 1.2 V

Play time:
[Approximate operating time in hours (in hold mode, at 25 ~C, on a flat, stable

surface).]

^

--..„.Function

Battery type''''~~---..„..

Tape

Radio

Microphone

recording

Radio

recording

Rechargeabie (A)

15.0

13.5

5.5

4.5

Panasonic alkaline

53.0

47.5

18.5

16.0

Both together (A)

68.0

61.0

24.0

20.5

(A) When the rechargeable battery (included) is fuily recharged (requires

2.5 hours).

•Operating conditions may reduce the operating times shown above.

Specifications are subject to change without notice.
Mass and dimensions are approximate.
