23

ENG

EN

G

LIS

H

SETTINGS

y

If you switch to another input, the SIMPLINK device

will stop.

y

If a third-party device with the HDMI-CEC function

is also used, the SIMPLINK device may not work

normally.

y

[Depending on model]

If you select or play media from a the device with a

home theatre function, the

HT Speaker(Speaker) is

automatically connected.

Be sure to connect with an optical cable (sold

separately) to use the

HT Speaker(Speaker)

function.

SIMPLINK function description

y

Direct Play : Plays the multimedia device on the TV

instantly.

y

Select multimedia device : Selects the desired

device via the SIMPLINK menu to control it from the

TV screen instantly.

y

Disc playback : Manages the multimedia device

with the TV remote control.

y

Power off all devices : When you power off the TV,

all connected devices are turned off.

y

Sync Power on: When the equipment with

SIMPLINK function connected HDMI terminal starts

to play, the TV will automatically turn on.

y

Speaker : [Depending on model]

Select speaker either on the home theatre unit or

the TV.

To set password

SETTINGS LOCK Set Password

Sets or changes the TV password.

The initial password is set to ‘0000’.

When France is selected for Country, password is not

‘0000’ but ‘1234’.

When France is selected for Country, password cannot

be set to ‘0000’.

To return Factory Reset

SETTINGS OPTION Factory Reset

All stored information is deleted and TV settings are

reset.

The TV turns itself off and back on, and all settings are

reset.

y

When

Lock System is in place, a pop-up window

appears and asks for password

y

Do not turn off the power during initialization.

To connect and use LG audio device

SETTINGS AUDIO Sound Out

LG Sound Sync (Optical)

[Depending on model]

Connect LG audio device with the

logo to the opti-

cal digital audio output port. LG audio device allows you

to enjoy rich powerful sound easily.

To use Headphone

SETTINGS AUDIO Sound Out Headphone

[Depending on model]

Sound is output through the headphone connected to

the earphone/headphone port.

To synchronize audio and video

SETTINGS AUDIO AV Sync. Adjust

[Depending on model]

Synchronizes video and audio directly when they do

not match.

y

If you set

AV Sync. Adjust to ON, you can adjust

the sound output (TV speakers or SPDIF) to the

screen image.

To use SIMPLINK

[Depending on model]

SIMPLINK is a feature that enables you to control and

manage various multimedia devices conveniently via

the SIMPLINK menu.

1 Connect the TV’s HDMI IN terminal and the

SIMPLINK device’s HDMI output terminal using an

HDMI cable.

y

[Depending on model]

For home theatre units with a SIMPLINK function,

connect HDMI terminals as above, and use an

optical cable to connect Optical Digital Audio

Out from the TV to Optical Digital Audio In of the

SIMPLINK device.

2 Select

INPUT(OPTION) SIMPLINK.

SIMPLINK menu window appears.

3 In SIMPLINK Setting window, set SIMPLINK

function to

ON.

4 In SIMPLINK menu window, selects the device you

want to control.

y

This function is only compatible with devices with

the SIMPLINK logo.

y

To use the SIMPLINK function, you need to use

a high-speed HDMI

®

cable (with CEC (Consumer

Electronics Control) feature added). High-speed

HDMI

®

cables have the No. 13 pin connected for

information exchange between devices.
