31 (E)
1. Select the pan/tilt head system using the CONTROL/
PREVIEW MONITOR OUT SEL button.
2. Use the following buttons to establish the modes.
 Press the IRIS button to establish the MANU mode
(the IRIS button’s lamp now goes off).
If the AUTO mode is established, the lens iris position
will not be entered.
 Press the TR/PSET button to establish the preset
memory mode (the TR/PSET button’s lamp now goes
off).
 If the M.LOCK button’s lamp lights, press the M.LOCK
button to establish the memory entry mode (the
M.LOCK button’s lamp now goes off).
3. Operate the ZOOM lever and PAN/TILT lever, and on the
monitor check the pictures which are to be shot.
4. Select the white balance from among the A, B and ATW
buttons, and adjust the lens iris using the FOCUS/IRIS
dial.
5. Set the unit to a state in which the MEMORY button is
held down.
When the MEMORY button is pressed, those buttons
among the TRACING/PRESET MEMORY buttons 1
through 50 in which data can be entered start flashing in
sequence.
If a button has a lamp that remains off, it means that
data has already been entered into it. Preset memory
data cannot be entered into it.
6. While the MEMORY button is held down, press the
button in which the preset memory data is to be entered.
7. If necessary, enter other shooting positions and settings
into other buttons among TRACING/PRESET MEMORY
buttons 1 through 50 as preset memory data.
8. Select the next pan/tilt head system using the
CONTROL/PREVIEW MONITOR OUT SEL button, and
continue setting the preset memory data for each system
concerned.
Entering preset memory data
Preset memory settings
The multi-function controller is equipped with a preset
memory function for entering the positions and settings with
which the pan/tilt head system is to shoot.
Preset memory data is entered into TRACING/PRESET
MEMORY buttons 1 through 50.
Operation
