24

Quick Reference Guide

Small Form Factor Computer

NOTICE:

Before touching anything inside your computer, ground yourself by touching an unpainted

metal surface. While you work, periodically touch an unpainted metal surface to dissipate any static
electricity that could harm internal components.

1 Follow the procedures in "Before You Begin" on page 20.
2 If you have installed a padlock through the padlock ring on the back panel, remove the padlock.
3 Slide the cover release latch back as you lift the cover.
4 Grip the sides of the computer cover and pivot the cover up using the bottom hinge tabs as

leverage points.

5 Remove the cover from the hinge tabs and set it aside on a clean, non-abrasive surface.

1

security cable slot

2

cover release latch

3

padlock ring

4

computer cover

4

2

1

3
