Quick Reference Guide

17

Ultra-Small Form Factor Computer — Front View

1

2

3

4

5

7

8

9

6

1

USB connectors (2)

Connect USB devices such as a mouse, keyboard, memory key, printer, joystick, and
computer speakers into either of the USB connectors.

2

headphone connector

Attach headphones to this connector.

3

microphone connector

Attach a microphone to this connector.

4

power light

The power light illuminates and blinks or remains solid to indicate different operating
states:

• No light — The computer is turned off.
• Steady green — The computer is in a normal operating state.
• Blinking green — The computer is in a power-saving mode.
• Blinking or solid yellow— See "Power Problems" in your online

User’s Guide.

To exit from a power-saving mode, press the power button or use the keyboard or the
mouse if it is configured as a wake device in the Windows Device Manager. For more
information about sleep modes and exiting from a power-saving mode, see "Power
Management" in your online

User’s Guide.

See "System Lights" on page 35 for a description of power light patterns that can help
you troubleshoot problems with your computer.

5

power button

Press this button to turn on the computer.

NOTICE:

To avoid losing data, do not use the power button to turn off the computer.

Instead, perform a Microsoft

®

Windows

®

shutdown.

6

vents

The vents allow air to flow through your computer. To ensure proper ventilation, do
not block these cooling vents.
