Without compromise!
Ohne Kompromisse!
Q-LINE QSC
Woofers with die-cast aluminum chassis and coated
polypropylene cone with neodymium magnet
1” tweeters with two-piece titanium dome in metal
housing with neodymium magnet
Q crossover with variable two-level tweeter output
Q - L I N E
7 / 8
QSC 210 QSC 213 QSC 216 QSC 164
PRINCIPLE
PRINZIP
2-Way Component System
2-Wege-Komponenten-System
2-Way Component System
2-Wege-Komponenten-System
2-Way Component System
2-Wege-Komponenten-System
Add-A-Woofer-System PRINCIPLE
PRINZIP
DIAMETER TWEETER / WOOFER
DURCHMESSER HOCH- / TIEFTÖNER
1“ / 4“ ( 25 mm / 10 cm ) 1“ / 5.25“ ( 25 mm / 13 cm ) 1“ / 6.5“ ( 25 mm / 16 cm ) - / 6.5“ ( - / 16 cm )
DIAMETER TWEETER / WOOFER
DURCHMESSER HOCH- / TIEFTÖNER
POWER HANDLING (W)
BELASTBARKEIT (W)
40 – 100 W 60 – 120 W 80 – 150 W 80 – 150 W
POWER HANDLING (W)
BELASTBARKEIT (W)
FREQUENCY RESPONSE (Hz)
ÜBERTRAGUNGSBEREICH (Hz)
56 – 32.000 Hz 50 – 32.000 Hz 35 – 32.000 Hz 35 – 280 Hz
FREQUENCY RESPONSE (Hz)
ÜBERTRAGUNGSBEREICH (Hz)
IMPEDANCE ( )
IMPEDANZ ( )
4 4 4 4
IMPEDANCE (Ω)
IMPEDANZ (Ω)
CROSSOVER FREQUENCY (Hz)
ÜBERTRAGUNGSFREQUENZ (Hz)
2.400 Hz / HP 250 Hz 2.500 Hz 2.400 Hz 250 Hz
CROSSOVER FREQUENCY (Hz)
ÜBERTRAGUNGSFREQUENZ (Hz)
