36
En
Playback
You can combine a video image from a video source with
sound from an audio source. For example, you can enjoy
listening to classical music while viewing beautiful
scenery from the video source on the video monitor.
Press the input selector buttons (3) to select a
video source and then an audio source.
y
• You can also select “MULTI CH” as the audio source (see
page 34). Press 4AMP and then press DMULTI CH IN.
• Set the “BGV” parameter in the “MULTI CH SET” menu to the
desired setting to select the default background video input
source of the MULTI CH INPUT sources (see page 63).
You can display the format, sampling frequency, channel,
bit rate and flag data of the current input signal.
1
Press 4
AMP and then KMENU.
The top “SET MENU” display appears in the OSD.
2
Press 7n repeatedly to select “SIGNAL
INFO” and then press 7
ENTER.
The audio information about the input source appears
in the OSD.
3
Press 7l / h to toggle between the audio
and video information displays.
4
Press K
MENU again to exit from “SET
MENU”.
■ Audio information
“–––” appears when this unit cannot display the corresponding
information.
■ Video information
“–––” appears when this unit cannot display the corresponding
information.
HDMI error and message
Playing video sources in the
background of an audio source
Displaying the input source
information
Audio sources
Video sources
DVD
V-AUX
DTV/CBL DVR
CD MD/CD-R TUNER
USB
DVD
SET MENU
TOP MENU
. ;AUTO SETUP
;MANUAL SETUP
.A;SIGNAL INFO
[ ]/[ ]:Up/Down
[ENTER]:Enter
p
p
Information Descriptions
FORMAT Signal format. When this unit cannot detect a
digital signal, it automatically switches to
analog input.
SAMPLING The number of samples per second taken from
a continuous signal to make a discrete signal.
CHANNEL The number of source channels in the input
signal (front/surround/LFE). For example, a
multi-channel soundtrack with 3 front
channels, 2 surround channels and LFE, is
displayed as “3/2/0.1”.
BITRATE The number of bits passing a given point per
second.
FLAG Flag data encoded in DTS, Dolby Digital, or
PCM signals that cue this unit to automatically
switch decoders.
Note
Information Descriptions
HDMI SIGNAL Type of the source video signals and the
video signals output at the HDMI OUT
jack of this unit.
HDMI RES. Resolution of the HDMI signals input or
output at the HDMI IN/OUT jacks of this
unit.
HDMI ERROR
(Only when error
is detected)
Error message for HDMI sources or
connected HDMI devices. See “HDMI
error and message” for details.
Note
Message Cause
DEVICE OVER The number of the connected HDMI
components is over the limit.
HDCP ERROR HDCP authentication failed.
OUT OF RES. The connected monitor is not compatible
with the resolution of the input video signal.
